Tractive force F1 150 - 1200 Newton
Progression 20 %
Piston rod Ø 10 mm, hard chrome-plated steel
Pressure pipe Ø 28 mm, black lacquered steel
Connections Blue galvanised steel

Standard strokes H (mm)

20, 50, 60, 70, 80, 100, 110, 120, 130, 150, 160, 180, 200, 210, 220, 250, 260, 300, 350, 360, 400, 450, 500, 600

Default length GL

L = 2 x H + 100
GL = L + L1 + L2

Standard scope of delivery

Valve on the piston rod

Extras

Fat chamber
Protection tube
Sealing system
Low temperature version
High temperature version
